Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors and Agents (RG-6X)

Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors and Agents (RG-6X)

Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors and Agents (RG-6X)
Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors and Agents (RG-6X)Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors and Agents (RG-6X)Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors and Agents (RG-6X)Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors and Agents (RG-6X)Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors and Agents (RG-6X)
RG-6X roll grooving machine for 2 -16 steel pipe. Capable to adjust the machine height as needed on construction sites
Categories
Roll Grooving Machine
Brand
Gruvmaster & Welping
Model
RG-6X
Fabrication Capacity
2"-16"(DN50-DN400) SCH10/40 Steel Pipe
Max Wall Thickness
10mm
Output Speed
23RPM
Power Supply
1100W
Packing Size
92*48*87cm
Gross Weight
170KG
FOB port
Shanghai/Ningbo
Terms of Payment
L/C, D/A, D/P, Western Union
Download
Update Time
Jun 19,2024
Detail Information
Pipe Roll Grooving Machine Video
Features of Electric Hydraulic Roll Groover Machine
● RG-6X Electric Hydraulic Roll Grooving Machine, specially crafted for creating roll grooves on lPS steel pipes ranging from 2" to 16" (DN50~DN400) SCH10 to SCH40. Perfect for use in workshops or on-site, this machine is equipped with a motor, hydraulic feeding pump, foot switch, and pipe stand for a complete roll grooving experience.
● The compact large-sized groove machine boasts exceptional versatility and robust performance. Its wide working size range and heavy-duty adjustable bracket make it suitable for varying-sized pipes.
● Specially designed roller set prevents flare on the pipe ends, and eases the installation of the grooved couplings.
● Inbuilt high-performance gear-reducing motor contributes to a compact size and low noise.
● The unique split-type hydraulic system prevents oil leaks and extends service life. Groove depth lock nut ensures high-quality grooves and high efficiency.
Pipe Roll Grooving Machine Parameter
8inch roll groover
Model:
RG-6X
Suitable materials:
Carbon Steel,SS Pipe
Fabrication Capacity:
2"-16" Pipe SCH10/SCH40
Power supply:
220V/110V
Frequency:
50HZ /60HZ
Max wall thickness:
10mm
Motor power:
1100W
Output speed:
23RPM
Packing gross weight:
170kgs
Packing size:
92*48*87cm
Standard Parts of RG-6X Roll Groover
Item Number
Description
Net weight
911022
Drive roller 2"~3" (Φ60~Φ89)
1.30kg
911021
Drive roller 3 ½”~6" (Φ101~Φ168)
1.30kg
911020
Drive roller 8”~12" (Φ219~Φ325)
1.40kg
911143
Drive roller 14”~16" (Φ355~Φ426)
1.60kg
912010
Groove roller 2"~3" (Φ60~Φ89)
0.45kg
912009
Groove roller 3 ½”~6" (Φ101~Φ168)
0.45kg
912008
Groove roller 8”~12" (Φ219~Φ325)
0.45kg
912052
Groove roller 14”~16" (Φ355~Φ426)
0.45kg
998026
Foot Switch
1.50kg
998103
Pipe stand for 2"~16" (Φ60~Φ426)
33.0kg
998011
Pipe Stabilizer
2.80kg
Optional Parts of RG-6X Roll Groover
Item Number
Description
Net weight
912040*
Groove roller for SCH10 Anti-flare (2"~3")
0.45kg
912039*
Groove roller for SCH10 Anti-flare (3½”~6")
0.45kg
912038*
Groove roller for SCH10 Anti-flare (8"~12")
0.45kg
912056*
Groove roller for SCH10 Anti-flare(14"~16")
0.45kg
Resources of RG-6X Roll Grooving Machine
RG-6X Breakdown Part List
RG-6X Roll Grooving Tool Operating and Maintenance Instructions Manual
Roll Grooving Machine Configuration
8inch roll groover
Hydraulic pump
High quality seal parts ensure long-term field usage without leaking
Fine-machined cylinder with accurate sizes
Proper-hardened piston rod of long-life
Built-in groove depth adjusting rod
8inch roll groover
Casting part
Reinforced cast iron housing for hydraulic pump, roller sets, pipe stabilizer
Support color customization
Balanced structure withstands tough jobs
8inch roll groover
Base & Parts
Pipe stabilizer to prevent pipe slipping
The complete steel base plate is High-strength, solid, and deformation-resistant.
Tool box * for easy stock of roll sets, tools, and parts
roll groover machine
Foot Switch
Removable foot switch with cable and plug
Safety operation choice
Light-weight and reliable
roll groover machine
Roll Sets
Available in sizes:
2"-3",3 1/2"-6",8"-12",14"-16"
For Steel pipe 2"-16" SCH10/40
High strength steel, hardened to withstand long-time usage
roll groover machine
Pipe Stand
Fine-machined steel body, bearing heavy weight Nylon roller heads, for smooth rotation,
Adjustable height to suit different size pipes 2"-16"
