Hydraulic Steel Pipe Roll Grooving Machine for 1 Inch to 8 Inch Steel Pipes (RG-1X)

Hydraulic Steel Pipe Roll Grooving Machine for 1 Inch to 8 Inch Steel Pipes (RG-1X)

Hydraulic Steel Pipe Roll Grooving Machine for 1 Inch to 8 Inch Steel Pipes (RG-1X)
Hydraulic Steel Pipe Roll Grooving Machine for 1 Inch to 8 Inch Steel Pipes (RG-1X)Hydraulic Steel Pipe Roll Grooving Machine for 1 Inch to 8 Inch Steel Pipes (RG-1X)Hydraulic Steel Pipe Roll Grooving Machine for 1 Inch to 8 Inch Steel Pipes (RG-1X)Hydraulic Steel Pipe Roll Grooving Machine for 1 Inch to 8 Inch Steel Pipes (RG-1X)Hydraulic Steel Pipe Roll Grooving Machine for 1 Inch to 8 Inch Steel Pipes (RG-1X)
Steel roll grooving machine for 1 inch -8 inch steel pipe for for piping systems & fire protection
Categories
Electric Hydraulic Roll Groover
Brand
Gruvmaster & Welping
Model
RG-1X
Fabrication Capacity
1"-8"(DN25-DN200)SCH10/40 Steel Pipe
Max Wall Thickness
8mm
Output Speed
23RPM
Power Supply
800W
Packing Size
73*40*77cm
Gross Weight
85KG
FOB port
Shanghai/Ningbo
Terms of Payment
L/C, D/A, D/P, Western Union
Update Time
Nov 10,2024
Detail Information
Pipe Roll Grooving Machine Features
Features of Electric Hydraulic Roll Groover Machine
● Model RG-1X Electric Hydraulic Roll Grooving Machine is designed to roll grooves on steel pipes and stainless steel from 1"-8" (DN25~DN200) SCH10/SCH40.
● Appropriate for various daily tasks involving fire-fighting pipes,this roll groover is a comprehensive tool that includes a motor, hydraulic feeding pump, foot switch, and pipe stand.
● The motor's built-in high-performance gear reduction system enables a compact design and reduced noise levels.
● The unique combination of the hydraulic feeding pump and the groove depth lock knob guarantees premium grooves and optimal efficiency.
Pipe Roll Grooving Machine Parameter
8inch roll groover
Model:
RG-1X
Suitable materials:
Carbon Steel,SS Pipe
Fabrication Capacity:
1"-8" Pipe SCH10/SCH40
Power supply:
220V/110V
Frequency:
50HZ /60HZ
Max wall thickness:
8mm
Motor power:
800W
Output speed:
23RPM
Packing gross weight:
85kgs
Packing size:
73*40*77cm
Standard Parts of RG-1C Roll Groover
Item Number
Description
Net weight
911042
Drive roller 1"-1 1/2"(φ33-φ48)
1.10kg
911043
Drive roller 2"-6"(φ60-φ168)
1.30kg
911044
Drive roller 8" (φ219)
1.40kg
912011
Groove roller 1"-1 1/2"(φ33-φ48)
0.40kg
912012
Groove roller 2"-6"(φ60-φ168)
0.45kg
912013
Groove roller  8" (φ219)
0.45kg
998078
Pipe stand
6.90kg
998033
Pipe Stabilizer
2.80kg
998026
Foot Switch
1.50kg
Ordering Information
Catalog No.
Phase
Power
900010
Single
800W,220V,50/60HZ
900011
Single
800W,110V,50/60HZ
Roll Grooving Machine Configuration
8inch roll groover
Hydraulic pump
High quality seal parts ensure long-term field usage without leaking
Fine-machined cylinder with accurate sizes
Proper-hardened piston rod of long-life
Built-in groove depth adjusting rod
8inch roll groover
Casting part
Reinforced cast iron housing for hydraulic pump, roller sets, pipe stabilizer
Support color customization
Balanced structure withstands tough jobs
roll groover machine
Roll Sets
Available in sizes:1"-1 1/2", 2"-6",8"
For Steel pipe 1"-8" SCH10/40
High strength steel, hardened to withstand long-time usage
roll groover machine
Pipe Stand
Quick size adjustable rods, fine-machined slots with latch
Steel ball heads,for smooth rotation,forward-backward moving of pipe
Adjustable height to suit different size pipes:1"-8"
8inch roll groover
Base & Parts
Pipe stabilizer ① to prevent pipe slipping; Steel tube bracket ② for handy grip
Complete steel base plate ③ High-strength, solid and deformation-resistant. Tool box ④ for easy stock of roll sets, tools and parts
roll groover machine
Thickened Steel Plate Base
Thickened steel plate base makes the machine stronger. More heavy duty
roll groover machine
Foot Switch

roll groover machine
Pipe Stablizer

Resources of RG-1C Roll Grooving Machine
RG-1X Breakdown Part List
RG-1X Roll Grooving Tool Operating and MaintenanceInstructions Manual
Pipe Roll Grooving Machine Comparasion
